Miniature Motion Control System Solutions

To create the most compact devices that impact everyday lives with
smaller time-to-market windows

Miniaturization has been a trend in the technology world, which always presents the challenge of reducing their size, especially for medical, laboratory, and industrial applications. As key components of motion-related products, miniature motors play an important role in reducing product size and increasing efficiency and reliability. To address the global trend of miniature motion applications, MOONS' continuously leverages leading miniature motion technologies and application know-how covering micromotors, gearheads, and intelligent drivers.

Wide Range of Miniature Motion Products & Cutting-edge Technologies

• The diameter of all Miniature Motors is 22mm or less, and the smallest is up to 8mm.

Widest range of micro motors products lines and cutting-edge technologies covering Hybrid Stepper Motors, Permanent Magnet Stepper Motors, Slotless Brushless DC Motors, Coreless Brush DC Motors, Brushless DC Motors, Gearheads, Encoders.



Miniature Motion Control System Solutions in Complete Kit

• Integrate Mini Motors, Gearheads, and Encoders with Intelligent Drivers to provide miniature motion control system solutions for Higher Power, Precision, and Efficiency in miniature motion.

• Continuously deliver the best-in-class products and customization services for your most compact applications.

Miniature Motion Control System Solutions

Motors + Gearheads + Encoders

Intelligent Drivers
(One-for-ALL)

Product Category

Product Series

Features

Frame Size

Speed

Torque

Available
Options

Built for high
performance and
Ease of Use

Hybrid Stepper Motors

Hybrid Stepper Motors

Hybrid Stepper Motors Structure

Click to enlarge



14H030H-0304/MS08HY
PTX05

• Optimized for High and
   Low Speed Operations
• Precise Positioning
   Control
• Position Hold
• Low Noise and Vibration
• Cost Effective

13mm~22mm

up to
10,000 rpm

up to
350 mNm

• Gearheads
• Encoders
• Drivers

Technosoft Motion
iPos Driver
iPOS2401
iPOS3604
one for all Various
modes of operation:
torque, speed or
position control

PM Stepper Motors

PM Stepper Motors

PM Stepper Motors Structure

Click to enlarge



PM08/PM10/
PG15/PM20/PG22

• Ease of position and
   speed control
• Linear torque/speed
   curve
• Torque proportional to
   current

15mm~22mm

up to
1000 rpm

up to
200 mNm

• Gearheads
• Encoders
• Drivers

Slotless Brushless DC Motors

Slotless Brushless
DC Motors

Slotless Brushless DC Motors Structure

Click to enlarge



ECU13026/ECU13038/
ECU16024/ECU16036/
ECH16056/ECH22045/
ECH22060/ECU22048

• High Power Density
• High Operating Speed
• Fast Dynamic Response
• High Winding Density
• No Cogging

13mm~22mm

up to
60,000 rpm

up to
200 mNm

• Gearheads
• Encoders
• Drivers

Coreless Brushed DC Motors

Coreless Brushed
DC Motors

Coreless Brushed DC Motors Structure

Click to enlarge



DCU08017/DCU10017/
DCU10025/DCU13020/
DCU13028/DCU16025/
DCU16035/DCU17025/
DCU17035

• Ironless winding
• Compact design
• Low current
   consumption
• No cogging
• Linear performance
   characteristic

8mm~17mm

up to
18000 rpm

up to
500 mNm

• Gearheads
• Encoders
• Drivers

Brushless DC Motors

Brushless DC Motors

Brushless DC Motors Structure

Click to enlarge



BLR16/R22

• Wide range of speed
   control and smooth
   torque output
• Excellent speed stability
• Small size, high power
• Low temperature rise,
   low noise, low vibration
• Long life, low
   maintenance costs
• Low positioning torque
• Energy efficient

16mm~22mm

up to
16000 rpm

up to
3000 mNm

• Gearheads
• Encoders
• Drivers

Applications

These miniature motors are ideal candidates for a wide range of applications that require tiny motors, especially in the field of medical devices and laboratory automation. These miniature motors are suitable for applications requiring a high degree of precision, such as miniature pumps, fluid metering and control, and optical sensor control. These motors can even be incorporated into motorized hand tools such as electronic pipettes and other handheld devices where mini motors were previously inaccessible.

Handheld Tools   Pinch Valves   Flow Control Valves   Optical Sensor Control   Optical/Aperture Control   Miniature Pumps
Handheld Tools   Pinch Valves   Flow Control Valves   Optical Sensor Control   Optical/Aperture Control   Miniature Pumps

Why MOONS'?

Customization

Customization

We can customize windings to ensure maximum torque and performance at a desired speed as well as customize the connections, shaft, and housing, and add an encoder. Our motors are designed to fit your application, not the other way around.

Small And Large Quantity Manufacturing

Small And Large Quantity Manufacturing

Our unique On-Demand manufacturing process is optimized for speed and efficiency, allowing us to make just a few units or as many as thousands of units at a time.

Online Ordering and Rapid Prototyping

Online Ordering and Rapid Prototyping

We have in-stock products in our webshop for online sales, so you can order online and receive your goods immediately. As a result, you can make working prototypes quickly, which allows you to begin critical testing of the application right away in order to get the product to market as quickly as possible.
(Homepage - https://www.moonsindustries.com/)

Ongoing Product Support

Ongoing Product Support

Once a customer, always a customer—MOONS' products are fully warranted and our experts are standing by to support you and your application whenever you need us.

About MOONS'

MOONS', a company listed on the Shanghai Stock Exchange - Stock Code 603728, is one of the largest integrated manufacturers of motion control and intelligent lighting with the yearly shipment of over 10 million stepper motors, motor drivers, led drivers mainly in US and Europe market. MOONS' stepper motors and motion control products are renowned for their high quality, high performance, and unique features and are specially designed for thousands of Engineers and Experts. They are widely used in a wide variety of innovative applications, including 3D printers, extruders, stage lighting, analytical and medical instruments, laser cutters, engravers, image scanners, textile machines, embroidery machines, precision telescope positioning systems, packaging machinery, CNC machines, and robotics. To get your creative ideas or innovative products to market as quickly as possible, we always work with you together. MOONS' - Experts' Choice!

About Technosoft Motion

Technosoft Motion was established in 1994, headquarter is located in Zug, Switzerland. With its known recognition of excellence, Technosoft Motion has pioneered the intelligent controller and drive in a single unit, as a cost-effective solution in many motion control applications, in over 75 countries. On March 13th (local time) 2019, MOONS' Electric (hereafter referred to as MOONS') and the shareholders of Technosoft Motion, Mr. Luciano Antognini and Mr. Liviu Kreindler, completed the transfer of shareholding rights in Switzerland. Technosoft Motion became a wholly owned subsidiary of MOONS'.
