Stepper motor, High torque, Low noise, Smooth movement, 2 phase, 1.8°, NEMA17
MS17HDBP4100
● High Torque, Low Losses, Small Size, High Efficiency
● Low Temperature Rise: Ideal for 3D printers, significantly less heat than other extruder motors
● Quieter & Smoother: Improved manufacturing processes makes these motors have a higher precision and more stable
● More Load & Longer Life: MOONS’ stepper motors use large bearings that can handle large axial and radial loads to ensure longer life
● Available options for Drives, Wire Harness, Flexible Coupling, Damper
● Low Temperature Rise: Ideal for 3D printers, significantly less heat than other extruder motors
● Quieter & Smoother: Improved manufacturing processes makes these motors have a higher precision and more stable
● More Load & Longer Life: MOONS’ stepper motors use large bearings that can handle large axial and radial loads to ensure longer life
● Available options for Drives, Wire Harness, Flexible Coupling, Damper
Brand Name:
MOONS'
Price:
USD
47.6
EA
Quantity:
Shipping to:
Lead Time:
working days
Lead Time:
Contact
customer service
customer service
Added to Your Shopping Cart
Payment Methods
Buyer Protection:
Free Exchange - current tab: Specification
- Torque Speed Curves
- Mechanical Size
- Downloads
- Recommended Options
- Delivery & Packaging
| Parameter | Unit | Value |
|---|---|---|
| Phase | 2 | |
| Step Angle | 1.8° | |
| Frame Size | NEMA17(42mm) | |
| Length | mm | 62.8 |
| Rated Current | A | 1 |
| Holding Torque | Nm | 0.82 |
| Holding Torque | oz-in | 116.13 |
| Resistance | Ohms ±10%@20℃ | 5.6 |
| Inductance | mH Typ. | 14.6 |
| Coil Type | Bi-Polar | |
| Detent Torque | mNm | 30 |
| Rotor Inertia | gcm² | 123 |
| Front Shaft Length | mm | 24 |
| Front Shaft Diameter | mm | 5 |
| Terminal Number | 4 | |
| Connect | Plug | |
| IP Rating | IP40 | |
| Insulation Class | B(130°C) | |
| Weight | kg | 0.6 |
| Certification |
UL RoHS |
|
| Shaft | Single |
Recommended Options
Filter By Product Type
All ProductsWire Harness
Coupling
Gearbox
Damper
Drive
Pulse/Direction Type
Profinet Type
EtherCAT Type
RS485 Type
Profinet Type
EtherCAT Type
RS485 Type
|
MS17HDBP4100
|
Torque
|
TEMP RISE
|
|
|---|---|---|---|
| 12Vdc 1A rms | |||
| 24Vdc 1A rms | |||
| 36Vdc 1A rms | |||
| 48Vdc 1A rms | |||
Click the curve symbol,
You can switch the display
Torque Optimization Configurator (Enter your voltage/current requirements to optimize the torque curve.)
|
Voltage V
|
Current A
|
||
|
|
|
►Dimensions
■ Motor Dimensions: mm（in）
■ Mating connector With Leads(order separately) Dimensions: mm（in）
 | |
2D Drawings
| Title | Type | Size（KB） | Download |
|---|---|---|---|
| MS17HDBP4100.pdf | 271 |
3D Model
| Title | Type | Size（KB） | Download |
|---|---|---|---|
| MS17HDBP_3D Model.step | STEP | 848 |
Torque Speed Curves
| Title | Type | Size（KB） | Download |
|---|---|---|---|
| MS17HD Series_Torque Speed Curve.pdf | 5213 |
Catalog
| Title | Type | Size（KB） | Download |
|---|---|---|---|
| Hybrid Stepper Motor_Catalog2019.pdf | 15487 |
