Stepper motor, High torque, Low noise, Smooth movement, 2 phase, 1.8°, NEMA24
MS24HS2P4150
● High Torque● High Efficiency● Low Noise,Low Losses● Available options for Wire Harness, Flexible Coupling
Brand Name:
MOONS'
Price:
USD
69.0
EA
Quantity:
Shipping to:
Lead Time:
working days
Lead Time:
Contact
customer service
customer service
Payment Methods
Buyer Protection:
Free Exchange | Parameter | Unit | Value |
|---|---|---|
| Phase | 2 | |
| Step Angle | 1.8° | |
| Shaft | Single | |
| Frame Size | NEMA24(60mm) | |
| Length | mm | 56 |
| Rated Current | A | 1.5 |
| Holding Torque | Nm | 1.9 |
| Holding Torque | oz-in | 269.08 |
| Resistance | Ohms ±10%@20℃ | 4 |
| Inductance | mH Typ. | 12.5 |
| Coil Type | Bi-Polar | |
| Detent Torque | mNm | 90 |
| Rotor Inertia | gcm² | 450 |
| Front Shaft Length | mm | 20.6 |
| Front Shaft Diameter | mm | 6.35 |
| Terminal Number | 4 | |
| Connect | Plug | |
| Insulation Class | B(130°C) | |
| Certification | UL,RoHS | |
| IP Rating | IP40 | |
| Weight | kg | 0.83 |
Recommended Options
Filter By Product Type
All ProductsDriver
Pulse Control Mode
Fieldbus Control Mode
Fieldbus Control Mode
|
MS24HS2P4150
|
Torque
|
TEMP RISE
|
|
|---|---|---|---|
Click the curve symbol,
You can switch the display
Torque Optimization Configurator (Enter your voltage/current requirements to optimize the torque curve.)
|
Voltage V
|
Current A
|
||
|
|
|
►Dimensions
■ Motor Dimensions: mm( in)
■ Mating connector With Leads(order separately) Part Number: 4634140201393 Dimensions: mm（in）
 | |
2D Drawings
| Title | Type | Size（KB） | Download |
|---|---|---|---|
| MS24HS2P4150 2D.pdf | 88 |
3D Model
| Title | Type | Size（KB） | Download |
|---|---|---|---|
| MS24HS2P_3D Model.step | STEP | 859 |
Torque Speed Curves
| Title | Type | Size（KB） | Download |
|---|---|---|---|
| MS24HS Series_Torque Speed Curve.pdf | 5832 |
Catalog
| Title | Type | Size（KB） | Download |
|---|---|---|---|
| Hybrid Stepper Motor_Catalog2019.pdf | 15487 |
