Stepper motor, High torque, Low inertia, Fast raising speed, 2 phase, 1.8°, NEMA42
ML42HS3L4600
● Low Inertia, Quick Response
● High Torque, High Efficiency
● Low Vibration, Low Noise
● High Torque, High Efficiency
● Low Vibration, Low Noise
Brand Name:
MOONS'
Price:
USD
600.0
EA
Quantity:
Shipping to:
Lead Time:
15
working days
Lead Time:
Contact
customer service
customer service
Payment Methods
Buyer Protection:
Free Exchange - current tab: Specification
- Torque Speed Curves
- Mechanical Size
- Downloads
- Recommended Options
- Delivery & Packaging
| Parameter | Unit | Value |
|---|---|---|
| Phase | 2 | |
| Step Angle | 1.8° | |
| Frame Size | NEMA42(110mm) | |
| Length | mm | 202 |
| Rated Current | A | 6 |
| Holding Torque | Nm | 31 |
| Holding Torque | oz-in | 4390.22 |
| Resistance | Ohms ±10%@20℃ | 1.02 |
| Inductance | mH Typ. | 22 |
| Coil Type | Bi-Polar | |
| Detent Torque | mNm | 800 |
| Rotor Inertia | gcm² | 16200 |
| Front Shaft Length | mm | 55.6 |
| Front Shaft Diameter | mm | 19.05 |
| Terminal Number | 4 | |
| Connect | Leads | |
| IP Rating | IP40 | |
| Insulation Class | B(130°C) | |
| Weight | kg | 11.6 |
| Certification |
UL RoHS |
|
| Shaft | Single |
Recommended Options
Filter By Product Type
All ProductsDriver
Pulse Control Mode
Fieldbus Control Mode
Fieldbus Control Mode
|
ML42HS3L4600
|
Torque
|
TEMP RISE
|
|
|---|---|---|---|
| 72Vdc 5A rms | |||
| 160Vdc 4.5A rms | |||
Click the curve symbol,
You can switch the display
Torque Optimization Configurator (Enter your voltage/current requirements to optimize the torque curve.)
|
Voltage V
|
Current A
|
||
|
|
|
►Dimensions
■ Motor Dimensions: mm（in）
2D Drawings
| Title | Type | Size（KB） | Download |
|---|---|---|---|
| ML42HS3L4600.pdf | 391 |
3D Model
| Title | Type | Size（KB） | Download |
|---|---|---|---|
| ML42HS3_3D Model.step | STEP | 1715 |
Torque Speed Curves
| Title | Type | Size（KB） | Download |
|---|---|---|---|
| ML42HS Series_ Torque Speed Curve.pdf | 5237 |
Catalog
| Title | Type | Size（KB） | Download |
|---|---|---|---|
| Hybrid Stepper Motor_Catalog2019.pdf | 15487 |
