Stepper motor, Ultra high torque, High efficiency, High accuracy, 2 phase, 1.8°, NEMA23
PL23HSAP4100
● Low Inertia,Quick Response
● High Torque,High Efficiency
● Low Vibration,Low Noise
● Available options for Drives, Wire Harness, Flexible Coupling, Damper
● High Torque,High Efficiency
● Low Vibration,Low Noise
● Available options for Drives, Wire Harness, Flexible Coupling, Damper
Brand Name:
MOONS'
Price:
USD
170.0
EA
Quantity:
Shipping to:
Lead Time:
working days
Lead Time:
Contact
customer service
customer service
Payment Methods
Buyer Protection:
Free Exchange - current tab: Specification
- Torque Speed Curves
- Mechanical Size
- Downloads
- Recommended Options
- Delivery & Packaging
| Parameter | Unit | Value |
|---|---|---|
| Phase | 2 | |
| Step Angle | 1.8° | |
| Frame Size | NEMA23(56.4mm) | |
| Length | mm | 77 |
| Rated Current | A | 1 |
| Holding Torque | Nm | 3.3 |
| Holding Torque | oz-in | 467.35 |
| Resistance | Ohms ±10%@20℃ | 8.8 |
| Inductance | mH Typ. | 32 |
| Coil Type | Bi-Polar | |
| Detent Torque | mNm | 150 |
| Rotor Inertia | gcm² | 460 |
| Front Shaft Length | mm | 20.6 |
| Front Shaft Diameter | mm | 6.35 |
| Terminal Number | 4 | |
| Connect | Plug | |
| IP Rating | IP40 | |
| Insulation Class | B(130°C) | |
| Weight | kg | 1.1 |
| Certification |
UL RoHS |
|
| Shaft | Single |
Recommended Options
Filter By Product Type
All ProductsDriver
Pulse Control Mode
Fieldbus Control Mode
Fieldbus Control Mode
|
PL23HSAP4100
|
Torque
|
