Stepper motor, Ultra high torque, High efficiency, High accuracy, 2 phase, 1.8°, NEMA23
PL23HS8L4360
● Low Inertia,Quick Response● High Torque,High Efficiency● Low Vibration,Low Noise● Available options for Drives, Flexible Coupling, Damper
Brand Name:
MOONS'
Price:
USD
107.0
EA
Quantity:
Shipping to:
Lead Time:
working days
Lead Time:
Contact
customer service
customer service
Payment Methods
Buyer Protection:
Free Exchange | Parameter | Unit | Value |
|---|---|---|
| Phase | 2 | |
| Step Angle | 1.8° | |
| Shaft | Single | |
| Frame Size | NEMA23(56.4mm) | |
| Length | mm | 55 |
| Rated Current | A | 3.6 |
| Holding Torque | Nm | 2.3 |
| Holding Torque | oz-in | 325.73 |
| Resistance | Ohms ±10%@20℃ | 0.63 |
| Inductance | mH Typ. | 2 |
| Coil Type | Bi-Polar | |
| Detent Torque | mNm | 100 |
| Rotor Inertia | gcm² | 260 |
| Front Shaft Length | mm | 20.6 |
| Front Shaft Diameter | mm | 6.35 |
| Terminal Number | 4 | |
| Connect | Leads | |
| Insulation Class | B(130°C) | |
| Certification | UL,RoHS | |
| IP Rating | IP40 | |
| Weight | kg | 0.65 |
Recommended Options
Filter By Product Type
All ProductsDriver
Fieldbus Control Mode
Pulse Control Mode
Pulse Control Mode
|
PL23HS8L4360
|
Torque
|
TEMP RISE
|
|
|---|---|---|---|
Click the curve symbol,
You can switch the display
Torque Optimization Configurator (Enter your voltage/current requirements to optimize the torque curve.)
|
Voltage V
|
Current A
|
||
|
|
|
►Dimensions
■ Motor Dimensions: mm（in）
2D Drawings
| Title | Type | Size（KB） | Download |
|---|---|---|---|
| PL23HS8L4360 2D.pdf | 86 |
3D Model
| Title | Type | Size（KB） | Download |
|---|---|---|---|
| PL23HS8L_3D Model.step | STEP | 1131 | |
| pl23hs8l 3D model | STEP | 1136 |
Torque Speed Curves
| Title | Type | Size（KB） | Download |
|---|---|---|---|
| PL23HS Series_Torque Speed Curve.pdf | 3618 |
Catalog
| Title | Type | Size（KB） | Download |
|---|---|---|---|
| Hybrid Stepper Motor_Catalog2019.pdf | 15487 |
